LCD Module 4 Wire Resistive Touch Panel Capacitive With Double
|Structure||F + G|
|Touch Life Span||>3,000,000 times|
|Scoring Life Expectance||>1,000,000 times|
|Supply Voltage||3.3V DV, 5V DC|
|Chattering Time||<10 MS|
|Operating Temperature||-20℃-70℃, <90%RH|
|Insulation Resistance||>20ΜΩ, 25V(DC)|
|Circuit Resistance||X(PIN1-PIN3): 400-1100Ω Y(PIN2-PIN4):100-500Ω|
1. Brief Information Upon 4 Wire Resistive Touch Panel
4 wire resistive touch is typically glass bottom and film top, but
they can be film + Film. It consists of a conductive bottom layer
of either glass or film and a conductive top film layer, separated
by extremely small, transparent spacer dots. A voltage is applied
across the conductive surface. When pressure from a touch is
applied to the top layer, it is compressed and makes contact with
the bottom layer resulting in a voltage drop. This change is
detected by the controller. By alternating the voltage signal
between the top layer and the bottom layer, the X and Y coordinates
of the user’s touch are computed. Each layer serves as one of the
